紫外杀菌灯的命名:

 例: GPH287T5L/MNBP GPHHA1554T6VH/4P

G

AA(AA)

BB(BB)

C

D(D)

E(E)

 /

FF(FF)

(GG)

Denotes “Germicidal” Lamp

Two to Four Character “Operation” Indicator

Two Digits: Lamp Length in inches

Four Digits: Lamp length in mm

Denotes Tubular Design “T”

Denotes Tube Diameter (Outside Diameter)

Denotes Glass Type:
L = Low Ozone Producing

VH = Very High Ozone Producing

Spacer

Denotes Base Type

Denotes Connection Type



PH = Preheat



T5 = 5/8″ (15mm)





4P = 4 Pin

SE = Single Ended



HO = High Output



T6 = 6/8″ (19mm)





SL = Slimline

DE = Double Ended



CL = Cell Lamp



T8 = 8/8″ (25mm)





MNBP = Mini Bi-Pin





U = U Lamp



T10 = 10/8″ (32mm)





MDBP = Med Bi-Pin





PHA = Preheat Amalgam



T12 = 12/8″ (38mm)











PHHA = Preheat Amalgam Horizontal High Output

















PHVA = Preheat Amalgam Horizontal or Vertical















G = 取杀菌英文单词“Germicidal”的首字母代表杀菌灯
PH = 预热型
HO = 高输出型
CL = Cell Lamp
U = U 型
PHA = 预热型的汞齐灯
PHHA = 水平安装的预热型高输出汞齐灯
PHVA =水平或垂直安装的预热型高输出汞齐灯

长度:

2位数: 命名中2个数字的其单位是英寸,通常指灯的安装总长度
3位数:命名中的3位数其单位为毫米,通常指的安装长度,既灯头到灯头的长度

管径 :

T = 管状 (1/8 inch)
5 = 5/8 inch (15mm)
6 = 6/8 inch (19mm)
8 = 8/8 inch (25mm)
10 = 10/8 inch (32mm)
12 = 12/8 inch (38mm)

玻璃类型

L = 低臭氧
VH = 高臭氧
/ = 间隔标志



灯头类型:

4P = 4针环形单端
MDBP = 标准型双端双针(G13; 12.7mm)
MNBP = 近孔双针 (G5; 5mm)
SL = 单针



连接方式:

SE = 双端单针
DE =双端双针
