CCFL Sub-Miniature Lamps



CCFL’s (cold-cathode fluorescent lamps) are strongly used for backlighting information and entertainment displays.

Fluorescent lamp-ends consume valuable power, generate heat, and cause shadows. They require lamp holders and must be concealed. One U-lamp can replace two straight lamps, eliminate two lamp-ends, and provide the same amount of light with less wattage. There is less wiring as well as fewer dark ends and lamp connectors to be hidden.

sub-miniature lampsThese benefits increase proportionately with multiple-bend lamps. Ballast design and dimming circuitry is simplified with fewer lamps and the display area can be made larger in comparison to the overall case size. Bent lamps with fewer lamp-ends tremendously improve efficiency of liquid crystal displays.

Sub-miniature fluorescent lamps are engineered and manufactured with the most advanced state-of-the art technology. In addition to being able to supply custom designed bent lamps and standard straight replacement lamps for all popular laptop computers, LCD Lighting is able to provide almost all replacement wiring harnesses, connectors, heaters, and heater assemblies.

Technical and Performance Specifications

Outside Diameter Range: 2.0mm, 2.4mm, 2.6mm, 3.0mm, 3.8mm, 4.8mm, 6.5mm, 8.0mm, 9.0mm   and 10.0mm
Length: 50mm – 500mm
Special: Lasered apertures available
Radius Bend: 2.0mm – 15.0mm
Shapes: “U”, “C”, “L”, “S”, “M” and multi-bend serpentine shapes
Colors:  Virtually any, as required and specified by the customer
Technology:  Sub-miniature cold-cathode fluorescent lamps (CCFL)
Avg. Operating Lifetime: Tens of thousands of hours depending on driving current (amps)
Operating Environment: Commercial, industrial, military and space environments
(-55°C to +85°C with thermal management)



Downloads

No matter which size or shape of miniature and sub-miniature fluorescent lamp you need – we can engineer, design and manufacture the lamps that will fit your unique application requirements. In over 27 years of manufacturing experience the Light Sources group and LCD Lighting have custom-designed for virtually every market application you can think of.

Download the design requirements data sheet today and send us your requirements to info@lcdl.com.
