Architectural

Architectural Lighting

LCD Lighting architectural lamps help beautify and illuminate academic and institutional, corporate, and hospitality buildings, monumental structures, residential, retail and entertainment applications, and site and facade lighting projects all over the world.

We manufacture high performance, internal reflectors with the most energy efficient lamps for exact OEM project requirements.  We offer both T8 and T12 Long Life technologies.

T5 & T8 Long Life (50,000 hrs.)
We designed our Long Life lamps for both, hot and cold (low-temperature) operating environments. The cold environment Long Life Lamp encapsulates the T8 lamp in a T12 sleeve providing a thermal insulation for the fluorescent tube to reach full brightness.  The T5 and T8 hot environment lamps use a long stem mount to create stable “cold spot” for optimum output and performance.

T12 Long Life (50,000 hrs.)
T12 Long Life lamps offer direct retrofitting with electronic and magnetic ballasts. They can directly replace existing T12 HO lamps with up to 25 percent greater efficiency. Whether building, designing, or retrofitting, the Long Life T12 is easy to incorporate into specific OEM applications. We have designed these lamps to operate on magnetic and electronic sign ballasts for easy changeover.

Architectural Lamps – Technical and Performance Specifications

  • Outside Diameter Range: T5 (15.9mm); T8 (25.4mm); T12 (38.1mm)
  • Length: 12” – 96”
  • Special: 97” – 120”
  • Radius Bend: 6mm – 25mm
  • Shapes: “U”, “C”, “L”, “S”, “M” and multi-bend serpentine shapes
  • Colors: Virtually any, as required and specified by the customer
  • Technology: HCFL or CCFL
  • Operating Lifetime: Tens of thousands of hours depending on driving current (amps)
    Operating Environment: Commercial, industrial, military and space environments
    (-55°C to +85°C with thermal management)
  • Manufacturing Process: LCDL (LCD Lighting) proprietary

Custom Shapes
We can customize any shape to meet individual OEM application design specifications.


Custom Colors
Readily available colors include: cool white, warm white, daylight, blue, green, red, and tri-band. We also provide ultraviolet and infrared phosphors. Colors can be blended to produce the precise desired color requirements in a wide range within the visible spectrum.

Please visit our High CRI page for more information.

voltarc_logo_white1

Are you looking for outdoor sign fluorescent lamps that reduce energy costs and work in a variety of environments? Our long life sign lamps from Voltarc – an LCD Lighting affiliate company – offer everything you need, including thermal and thermal diffused lamps for cold operating environment. Click here to learn more.
